HeatCube 5 kW Pool Heat Pump

The HeatCube 5 kW heat pump extends the bathing season and ensures a pleasant, stable temperature in your pool – even when the weather changes. The compact and quiet unit is designed for outdoor use and is easy to integrate into existing pool setups and filtration systems. The heat pump is ideal for pools up to 20,000 litres and operates even at outdoor temperatures as low as –7 °C. Control is flexible and user-friendly – either directly on the integrated control panel or via smartphone using the dedicated WiFi app. A reliable solution for anyone who wants comfortably heated pool water.

Product features
• User-friendly and energy-efficient Plug & Play heat pump with WiFi control
• Suitable for pools with a max. pool volume of 20,000 litres
• Reliable operation from –7 °C up to +43 °C outdoor temperature
• Quiet operation with just 46 dB measured at a 1-metre distance
• Significantly reduces energy consumption compared to traditional electric heaters

Efficient heating
The HeatCube 5 kW delivers pleasant warmth to pools with a recommended pool volume of up to 17,500 litres and can handle a max. volume of 20,000 litres*. It is designed to work effectively in both cold and warm weather – even down to –7 °C – allowing you to start the bathing season earlier and extend it into the autumn.

Flexible WiFi control
The heat pump features an intuitive control panel where you can easily set your desired temperature. Thanks to the integrated WiFi function, you can monitor and control the pump directly from your smartphone – quickly, easily and flexibly, no matter where you are.

Quiet operation
With a noise level of just 46 dB measured at 1 metre, the HeatCube 5 kW is especially suitable for private gardens where comfort and peace are important. 46 dB is roughly equivalent to a quiet conversation, making the pump discreet in operation.

Energy-saving performance with high COP
With a COP value of up to 5.1, the heat pump is an energy-efficient alternative to traditional electric heaters. For every kWh of electricity used, the unit returns over 5 kWh of heat energy to the pool. This results in significantly lower operating costs and a more economical heating solution.

Durable titanium heat exchanger
The pump is equipped with a titanium heat exchanger that withstands both chlorinated and saltwater. This provides maximum durability and corrosion resistance, ensuring long life and consistent performance year after year.

Protected for outdoor use
With a protection rating of IPX4, the pump is built to withstand rain, humidity, and harsh Nordic weather. Its compact size and sturdy construction make it easy to place in most gardens without taking up unnecessary space.

How to get the most out of your heat pump
To ensure the best operating conditions, it is recommended to use a summer cover on your pool when not in use. This reduces heat loss and makes heating more efficient. Also, make sure the water flow through the pump is properly adjusted, as this ensures the most stable and energy-efficient operation. Regular cleaning of the filtration system and unobstructed air circulation around the unit will help extend its lifespan and maintain optimal performance.

Specifications
Item number: 1460
EAN: 5704841014602
Maximum pool volume, m³*: 20,000
Maximum recommended pool volume, m³: 17,500
Temperature setting range (cooling/heating), °C: 8–40
Operating temperature range (air), °C: –7–43
Compressor type: Rotary
Power supply V/Ph/Hz: 220–240V~/50Hz
Rated current A: 4.67 A
Rated fuse A: 9.34 A
Recommended water flow in operation, l/h: 1800
Max. water pressure drop, kPa: 2.1
Heat exchanger: Titanium
Water connection inlet/outlet, mm: 32 / 38
Fan quantity: 1
Fan speed, RPM: 700
Fan power input, W: 25
Noise at 1 metre distance, dB(A): 46
Refrigerant type: R32
Refrigerant amount, g: 300
CO₂ equivalent, tons: 0.20
Protection: IPX4

At air 27 °C / water 26 °C / humidity 80%*
Heating capacity, kW: 5.0
Power consumption, kW: 0.98
COP: 5.1

At air 15 °C / water 26 °C / humidity 70%*
Heating capacity, kW: 3.5
Power consumption, kW: 0.88
COP: 4.0

Dimensions and weight
Net dimensions L/W/H, mm: 420 x 350 x 380
Gross dimensions L/W/H, mm: 450 x 420 x 400
Net/Gross weight, kg: 24 / 26

* From April to October, with full insulation, pool cover, sheltered from wind, and in full sun.
